Polyvinylchloride (PVC) Suction Hose

Polyvinylchloride (PVC) Suction Hose
NEWFLEX reinforced suction hose is widely used throughout industry in both positive and negative pressure applications. Its advanced design allows the use of light-weight, corrosion-resistant PVC to replace bulkier and heavier ply-wrapped rubber hose.

NEWFLEX series 'FH' and 'FHS' are clear, allowing the user to have full visual flow of material. The Food Grade lines are made from FDA-approved ingredients suitable for food and beverage handling. The smooth interior is easily sterilized and cleaned. Both types have a vacuum rating of 28 in./Hg.

NEWFLEX series 'VFH' is produced from a clear FDA liner with an industrial grade white helix, which is not exposed to the hose I.D. It can handle light-duty pressure discharge, gravity feed, and moderate vacuum applications.


Advantages

  • 100% PVC construction
  • Spiral reinforcement made from rigid PVC to resist impact, crushing, and kinking
  • Lighter than ply-wrapped rubber and other similar hoses
  • Available in Food and Industrial Grades
  • Food Grade made from non-toxic ingredients conforming to FDA and 3A standards
  • Smooth interior produces low friction loss permitting maximum flow

Physical Properties

                                                 Series            Series
                                                FH & FHS         VFH
Hardness, Shore A +/- 5               65                       70
Tensile Strength, psi                   1900                   2000
Elongation at Break, %                 440                     420
Brittle Temperature, Deg F      -45 Deg F           -42 Deg F
Max. Operating Temperature     150 F                  140 F
